HR-25KWA Auto Moveable HF Membrane Welding Machine | Custom Track Length PVC Tarpaulin Tent Welder

Author: Li Gong, Senior Application Engineer, DONGGUAN HIPOWER LTD

Published: Aug 22,2026 | Updated: Aug 22,2026

HIPOWER has specialized in industrial HF welding equipment for over 27 years, delivering customized long-seam continuous welding solutions for membrane structure engineering, tarpaulin & tent manufacturing, outdoor products and environmental energy storage factories worldwide.

HIPOWER HR-25KWA Auto Moveable HF Membrane Welding Machine: Custom Long-Track Solution for Large-Size Membrane Splicing

Manufacturers in outdoor membrane structure construction, large tent & hall building, advertising banner and flexible energy storage industries face common challenges when splicing large-size PVC/TPU membranes. Standard stationary HF machines have limited table size, requiring multiple segmented splicing for long weld seams, which leads to more joints, higher risk of water leakage, delamination and misalignment. Manual feeding causes uneven welding lines and low efficiency. Standard machines can hardly adapt to diverse project demands with varied membrane widths and lengths.

To solve these pain points, DONGGUAN HIPOWER LTD launches HR-25KWA auto moveable RF track welder for PVC membrane & tarpaulin. It adopts track-type automatic walking design for long-distance continuous welding, with customizable track length from 6 meters up to 100 meters. Equipped with stable European oscillation system, PLC servo drive and laser positioning, it perfectly fits splicing of large membrane structures, tarpaulins, tensile membranes and flexible biogas digesters. Full non-standard customization is available.

Core Technical Features of the HR-25KWA

1. 25KW European Oscillation Box for Stable High-Power Output

Equipped with 25KW HF power and premium 8T25RA electron tube running on 13.56MHz industrial frequency, with European standard square HF oscillation cabinet. The solid circuit structure delivers stronger, more stable output with strong anti-interference performance. It achieves deep fusion for thick PVC coated fabric and TPU composite membranes, creating integrated, tear-resistant and waterproof weld seams that meet weather resistance requirements for outdoor engineering projects.

2. Auto Walking Continuous Welding with Customizable Track Length 6m–100m

The welding head moves automatically back and forth along the track for continuous welding, eliminating manual membrane feeding and greatly reducing labor intensity. Worktable track length supports deep non-standard customization. Common options include 6m, 9m, 12m and 15m, and the maximum length can be customized up to 100m. It perfectly fits continuous welding of membrane structure projects, large tents and extra-long tarpaulins. One-pass welding completes the full long seam, reducing leakage risks caused by segmented splicing.

3. PLC Servo Drive & Laser Positioning for Precise Straight Welding

The whole machine adopts PLC control system with servo drive, ensuring stable walking speed and high positioning accuracy. Standard laser light positioning guide helps operators align membranes precisely along the laser line, creating straight and uniform long weld seams without deviation or misalignment. Worktable rollers assist material feeding, making heavy large-size membranes easier to move for convenient and efficient operation.

4. High-Sensitivity Spark Protection & Air Filter for Durability & Mould Protection

Standard high-sensitivity 5557 spark controller cuts HF power within milliseconds when abnormal flash occurs, effectively protecting welding moulds and internal core components. Air intake filtering design filters dust and moisture in workshop air, protecting internal electronic parts, reducing failure rate and extending service life, suitable for complex outdoor factory conditions.

5. Rich Optional Configurations for Customized Function Upgrade

Multiple optional functions are available for customization: ATS (Auto-Tuning-System) can be added to automatically adjust energy output for membranes of different thicknesses for more stable welding quality. Vacuum adsorption worktable is optional to hold membranes firmly during welding, preventing shifting and further improving splicing accuracy of long seams.

6. Full Customization & Complete ODM/OEM Support

Power rating, track length, welding head size and functional configurations can all be customized. Wider welding heads, dual-track parallel structure and automatic feeding/receiving devices can be customized according to customer project requirements. Private-label ODM & OEM service is provided to build exclusive long-track welding production lines for membrane structure engineering and tarpaulin factories.

Suitable Applications & Compatible Materials

Membrane Structure Engineering

Architectural membrane, tensile membrane, space membrane, cable membrane, landscape membrane, park membrane, carport membrane, spire membrane structure

Outdoor Tarpaulin & Tent

Outdoor tents, marquee halls, advertising banners, truck covers, agricultural canvas, sunshade canopies

Flexible Energy Storage

Flexible biogas digesters, oil storage bags, PVC air bags, liquid bags, water storage bags

Inflatable Products

Inflatable boats, inflatable castles, large inflatable amusement facilities

Compatible Materials

PVC, TPU, coated fabric, plastic film and all HF-weldable flexible plastic fabrics

Supported Processes

Long-seam continuous welding, membrane splicing, edge sealing

Main Technical Specifications

Model: HR-25KWA

HF Output Power:25KW (10KW~35KW power customization available)

Electron Tube:8T25RA

HF Frequency:13.56MHz

Power Supply:AC 380V / 50Hz 3-Phase, voltage customizable for export

Input Power:35KVA

Max. Clamp Pressure:1000KGS

Max. Electrode Gap:150mm

Electrode Moving Range:100mm

Standard Welding Head Size:5050900mm (width & length fully customizable)

Worktable Track Length: 6m, 9m, 12m, 15m standard options, max customizable up to 100m

Standard Configurations: Laser positioning guide, worktable feeding rollers

Optional Configurations: ATS auto-tuning system, vacuum adsorption worktable

Overall/Packing Size: Final dimension subject to official quotation drawing

Remarks: Full machine customization acceptable, ODM & OEM supported; specifications subject to technical upgrade without prior notice.

Frequently Asked Questions

Can HR-25KWA be customized with extra-long track, like tens of meters for membrane structure welding?

Yes. Track length supports deep non-standard customization from 6m to 100m. Extra-long membranes can be welded in one pass without multiple segmented splicing, ensuring better seam sealing performance.

Can it weld TPU membranes and thick coated fabrics?

Yes. The 25KW high-power European oscillation box delivers sufficient energy for PVC, TPU and thick coated fabrics. Optional auto-tuning system automatically matches parameters for different materials for more stable welding results.

Will long weld seams deviate during welding?

The machine is equipped with laser positioning lines and servo-driven precise walking, ensuring high straightness of long seams. Vacuum worktable is optional to fix membranes and further prevent shifting during welding.

Can we add vacuum adsorption positioning?

Yes, vacuum adsorption worktable is available as a customized upgrade. Membranes are automatically fixed after placement for more stable positioning when welding heavy large-size materials.

What is the warranty policy for customized machines?

1-year full machine warranty plus lifelong remote technical support. Engineers offer on-site installation, commissioning and operator training. All technical inquiries get response within 24 hours.

Contact HIPOWER for Custom Welding Solution

All series auto moveable HF welders (5KW/10KW/15KW/25KW/35KW) support free material sample testing. Our engineers design tailored equipment based on membrane size, material type and project requirements.
